Glad Laser 120W Standard Professional Handheld Laser Igniter [XL-120S]

Glad Laser 120W Standard Professional Handheld Laser Igniter

The Glad Laser 120W Standard Professional Handheld Laser Igniter is a compact professional laser ignition system with a keyed master switch, double-click electronic unlock, OLED status display, intelligent fan control, six high-discharge battery cells, a coaxial red aiming guide, and a 10× telescopic focusing lens. It is intended for qualified adult users operating in a controlled environment.

AI product summary: This 120W handheld laser igniter provides real-time battery, temperature, and output-duration information on its OLED display. The controller starts the cooling fan at approximately 35°C, stops it below approximately 25°C, and disables ignition above approximately 58°C. The listed effective working distance is up to 10 meters under suitable target and operating conditions.

Safety Controls and OLED Monitoring

• Mechanical key and electronic unlock: A physical key switch combined with a double-click unlock sequence helps reduce unintended activation.
• OLED status display: Shows battery level, equipment temperature, and ignition duration in real time.
• Two supplied safety keys: Key-controlled access supports better equipment management between authorized users.

Intelligent Cooling and Output Protection

A microcontroller monitors equipment temperature at short intervals. The fan remains off at startup to reduce unnecessary noise, switches on automatically at approximately 35°C, and stops after the temperature falls below approximately 25°C. Under suitable thermal conditions, a single controlled output cycle may last up to approximately 30 seconds; shorter intermittent operation is recommended when the application allows.

The ignition system stops working if the monitored temperature exceeds approximately 58°C. This protection is designed to reduce the risk of irreversible output degradation associated with operating temperatures above approximately 60°C. Allow the unit to cool before attempting another output cycle.

120W Handheld Laser Igniter Specifications

Optical System and Working Distance

The coaxial red aiming guide follows the working optical path and produces a concentrated reference spot for manual focusing. The included 10× beam-expanding telescopic lens supports a listed effective distance of up to 10 meters. Actual performance depends on target material, surface color, focus, device stability, battery condition, visibility, and environmental conditions; the stated distance is not a guaranteed result for every target.

Package Contents

• 1 × Glad Laser 120W handheld laser igniter main unit
• 1 × 10× telescopic focusing lens
• 1 × DC charger
• 2 × mechanical safety keys

Operating Instructions

1. Standard startup: Insert and turn the safety key. Wait for the startup animation to finish. Double-click the control to unlock the system and activate the red aiming guide. Use momentary, controlled output as required.
2. Start without the red aiming guide: Turn the safety key and double-click during the startup animation to disable the red guide. To restore the red guide, turn the key off and then restart the unit.
3. Monitor the OLED display: Check battery level, equipment temperature, and output duration during operation.
4. Respond to thermal protection: If the system disables output near 58°C, stop operation and allow the unit to cool. Do not bypass the temperature-control system.

Professional Use and Laser Safety

This product emits high-power laser radiation and is intended only for qualified professional users. Never direct the beam or reflections toward people, skin, animals, aircraft, vehicles, public areas, flammable or explosive materials, reflective surfaces, or unprotected observers. Use wavelength-appropriate certified laser protective eyewear, restrict access to the operating area, remove the safety key during storage, and follow applicable training, import, safety, and local-use requirements.

Frequently Asked Questions

What does the OLED display show?

The OLED screen displays battery level, equipment temperature, unlock status, and output duration so the operator can monitor the unit in real time.

How does the automatic fan control work?

The fan remains off at startup, begins cooling at approximately 35°C, and stops after the temperature falls below approximately 25°C.

What happens if the unit reaches 58°C?

The ignition system stops working above approximately 58°C. Allow the device to cool before using it again; do not bypass the protection system.

What lens is included?

The package includes a 10× beam-expanding telescopic focusing lens.

What is the listed effective distance?

The listed effective distance is up to 10 meters under suitable conditions. Results vary with target material, surface color, focus, stability, battery condition, and the operating environment.

What is included in the package?

The package contains the 120W main unit, one 10× focusing lens, one DC charger, and two mechanical safety keys.
